Product benefits

Kaifoam PE is a CE-compliant closed-cell insulation material made of quality polyethylene that is used to insulate pipes carrying heat and cold in sanitary and heating technology. The silver-grey pipe insulation reliably minimises energy losses in unheated rooms of commercial and residential buildings such as detached houses and apartment blocks thanks to low thermal conductivity of ≤0.040 W/(m·K) at +40 °C or +10 °C mean temperature. These thermal properties reliably prevent either condensation from forming or pipes freezing over the entire service life of the heating system.

At the same time, Kaifoam PE also acts as sound insulation by muffling liquid flow and ticking noises from adjacent building components. Dust- and fibre-free, it meets increased hygiene requirements while contributing to a positive indoor climate.

Wide product range

The portfolio offers further insulation solutions (e.g. Kaifoam PE-RO), which have an additional coating of a particularly resistant protective polymer film. Thanks to this stable surface, they are perfect for insulating pipes under plaster in the wall and floor areas that are subject to heavy mechanical loads.

The angular Kaifoam PE-DHplus insulation sleeves are made from high-quality polyethylene and have been specially designed for insulating heating pipes in floor construction above rooms which are in contact with the ground, unheated rooms, as well as in false ceilings.

Kaifoam PE-DWS is a PE thin-walled tube with inner and outer foil for copper pipes, Kaifoam PE-AB is a PE insulation for sewage pipes, and the Kaifoam PE-STR insulation strip rounds off the Kaifoam PE range.

Easy attachment

Kaifoam PE insulation material is easy to work with, as the semi-flexible tubes are supplied slit so they can be simply pushed onto the pipe. There is a wide range of tape accessories and PE clips for secure attachment. Kaifoam PE tubes are also available in a self-adhesive version. Kaifoam PE generates a positive return on investment in just a short time.

Read more
Read less

Product highlights

Piktogram, Tepelná účinnost

Excellent thermal values minimise energy losses

Inadequately insulated technical installations generate increased operational costs. Kaiflex has low thermal conductivity, which results in lower energy losses and increases the efficiency of the entire installation.

Piktogram, Antimikrobiální

Anti-microbial finish

Mould growth can affect indoor air quality. Kaiflex provides effective protection against moisture penetration, is naturally anti-microbial and resistant to mould growth, leaving bacteria no chance.

Piktogram, Snížení hluku

Effective sound insulation performance reduces noise pollution

Acoustic comfort improves the quality of life. Kaimann products have sound-absorbing properties that reduce the noise level of technical equipment and contribute to a quieter environment.

Documents

Download center

Insulation thickness calculator Kaicalc

Those who pay attention to careful planning, workmanship and quality in a project design, can avoid costly system malfunctions or even failures and can thus keep operating costs stable in the long term - or even reduce them sustainably. Decisive for this is both the choice of the right insulation material and the correct calculation of insulation thickness. Our insulation thickness calculator Kaicalc provides reliable support around the clock.

Go to Kaicalc
